Description
8-Port PCIe RS-232/422/485 Terminal Block 2KV Optical Isolation, DA-720 Peripherals Modules
Serial Interface
-
Baudrate
- 50 bps to 921.6 kbps
-
Connector
- Terminal block
-
Data Bits
- 5, 6, 7, 8
-
Flow Control
- ADDC® (automatic data direction control) for RS-485, RTS/CTS, XON/XOFF
-
Isolation
- 2 kV
-
Parity
- None, Even, Odd, Space, Mark
-
Pull High/Low Resistor for RS-485
- 1 kilo-ohm, 150 kilo-ohms
-
Serial Standards
- RS-232/422/485
-
Stop Bits
- 1, 1.5, 2
-
Surge
- 2 kV
-
Terminator for RS-485
- 120 ohms
Serial Signals
-
RS-422
- Tx+, Tx-, Rx+, Rx-, GND
-
RS-485-2w
- Data+, Data-, GND
-
RS-485-4w
- Tx+, Tx-, Rx+, Rx-, GND
-
RS-232
- TxD, RxD, RTS, CTS, GND
Physical Characteristics
-
Dimensions (without ears)
- 213.31 x 95 mm (8.398 x 3.74 in)
-
Weight
- 395 g (0.87 lb)
Environmental Limits
-
Operating Temperature
- -25 to 55°C (-13 to 131°F)
Declaration
-
Green Product
- RoHS, CRoHS, WEEE
MTBF
-
Time
- 463,644 hrs
-
Standards
- Telcordia (Bellcore), GB
Warranty
3 years
